U3372 4G USB WIFI High Speed Portable Wi-Fi Hotspot with Sim Card Slot

Item U3372 4G USB Technical Specification V1.0

Basic Product Information

Item

Description

Model No.

U3372

4G Wireless Access Point and USB dongle

Size

92.5mm*28mm*11mm

112*72*20(outer packing)

Weight

30g

HW Description

Item

Remarks

Hardware platform

FLASH + RAM

2Gbit Flash+1Gbit DDR2

Chipset

Qualcomm MDM9207

Introduction

The chip support 4G/3G/2G mobile network access service. Up to 10 users sharing 4G data by  WIFI at the same time.MDM9207 has more Stable performance and Lower power, English/French/German/Spanish/Portuguese/Arabic language supported, R&D team and factory owned give you full technical support and OEM service

Europe, Asia and Africa Frequency

FDD-LTE

B1/B3/B5/B7/B8/B20 /B28

TDD-LTE

B38/B40/B41

WCDMA

B1(2100Mhz)/B5(850Mhz)/B8(900Mhz)

GSM

850/900/1800/1900Mhz

North America South America Edition Frequency

FDD-LTE

B1/B2/B4/B5/B12/B17/B25/B28/B66

TDD-LTE

WCDMA

B1(2100Mhz)/B2(1900Mhz)/B4 (800Mhz )/B5 (850Mhz )

GSM

850/900/1800/1900Mhz

Peak Rate

FDD-LTE

Cat 4, DL 150 Mbps ,UL50Mbps

TDD-LTE

Cat 4, DL 130 Mbps ,UL35Mbps

UMTS/WCDMA

DL 42Mbps, UL 5.76Mbps

EDGE/GPRS

DL 473.6Kbps, UL 171.2Kbps

Antenna

 main/pole antenna

FPC

WiFi Information

Item

Remarks

Standard

IEEE 802.11n

support 150Mbps

IEEE 802.11g

support

IEEE 802.11b

support

IEEE 802.11b/g/n

support

IEEE 802.11b/g

support

Wifi Chipset

WIFI 802.11b/g/n

realtek RTL8189ES

Frequency

Europe, China

2.4G

U.S.A

2.4G

Japan

2.4G

RF antenna

2*2 MIMO

FPC

Wifi Feature

transmission distance

Default coverage radius 100 m (open environment)

1~11 Channel (North America / Canada)

support

1~13 Channel (Europe / Australia)

support

1~14 Channel (Japan)

support

SSID broadcast

support

Security and encryption

WPA-Personal、WEP(64-Bit)、WEP(128-Bit)
